Vibration Motor Module

39 pc(s)
RBT-03026

$8.00

This small vibratory motor module is perfect for non-audible indicators. Use in any number of applications to indicate to the wearer when a status has changed. The on-board MOSFET driver allows the module to interface directly to microcontroller. Features : Operating voltage:...
+

This small vibratory motor module is perfect for non-audible indicators. Use in any number of applications to indicate to the wearer when a status has changed. The on-board MOSFET driver allows the module to interface directly to microcontroller.

Features:

  • Operating voltage: 3.0-6.0VDC
  • Rated speed: 9000 rpm minimum
  • Rated current: 60 mA
  • Start current: 90 mA
  • Starting voltage: 3.7V
  • Insulation resistance: 10M Ohm

Dimensions: 23(W) x 21(L) x 5(H) mm
