Analog Capacitive Soil Moisture Sensor- Corrosion Resistant

8 pc(s)
SEN-02220

$14.90

This product measures soil mositure levels by capacitive sensing, rather than resistive sensing like other types of moisture sensor. It is made of a corrosion resistant materal giving it a long service life. Insert it into soil and impress your friends with the real-time soil moisture data!...
+

This product measures soil mositure levels by capacitive sensing, rather than resistive sensing like other types of moisture sensor. It is made of a corrosion resistant materal giving it a long service life. Insert it into soil and impress your friends with the real-time soil moisture data!

The product includes an on-board voltage regulator which gives it an operating voltage range of 3.3 ~ 5.5V. It is compatible with low-voltage MCUs (both 3.3V and 5V logic). To make it compatible with a Raspberry Pi, an ADC converter is required.

Specification

  • Power supply: 3.3V to 5VDC
  • Output voltage signal: 0 ~ 3.0VDC
  • Current: 35mA
  • Pin definition:
    • Analog output(Blue wire)
    • GND(Black wire)
    • Power(Red wire)
  • Size: 98mm x 23mm
Documents:
